A rare Atlantic Technology 7 channel power amplifier. Fully working with no issues. A cosmetic defect of unknown origin as photographed. Priced adjusted accordingly.
This is a heavy at 30+ kilos and hence pickup only.
Specifications
Power Output 7 x 120 watts @ 8 ohms, 20 - 20kHz, 0.08% THD
Frequency Response 20Hz. -20kHz. +/- 0.3 dB at rated output
Total Harmonic Distortion (THD) Less than 0.08% at all frequencies, less than 0.008% at 1 kHz
Power Bandwidth 10Hz - 100 kHz +0/-3 dB
Crosstalk Greater than -90 dB from 20 Hz to 20Khz
Voltage Gain 29dB
Input Impedance 27k ohms
Input Sensitivity 1.2 Volts for Full Rated Output
Remote Trigger Voltage 3 - 18 Volts AC/DC
Dimensions (HxWxD) 7.75” x 17.2” x 18” , 197mm X 437mm X 453mm
Weight 67.25 lbs net, 31 kg
Power Requirements 230VAC, +/- 3%, 50Hz - 60 Hz. 1800 watts, maximum
