DSP AZ2

9 months ago 361

Experience high-fidelity audio with the Yamaha DSP-AZ2, a robust secondhand A/V receiver designed for impressive performance in home theater setups. Capable of delivering 130 watts per channel into 8Ω speakers for both stereo and surround sound, the DSP-AZ2 ensures powerful, clear audio across your entire system.

With a frequency response range extending from 10Hz to 100kHz, this receiver provides exceptional detail and depth in audio reproduction. Its total harmonic distortion is remarkably low at 0.02%, guaranteeing a pure sound without unwanted noise. The damping factor of 200 helps maintain tight control over your speakers, enhancing bass precision and overall sound quality.

The DSP-AZ2 features a comprehensive set of connections, including coaxial and optical digital inputs, as well as component, composite, and SVHS video connections, allowing for flexible integration with various audio and video sources. The receiver’s input sensitivity includes 2.5mV for moving magnet (MM) and 150mV for line inputs, with a signal-to-noise ratio of 80dB (MM) and 96dB (line) for clean, interference-free sound.

Measuring 435 x 191 x 453mm and weighing 22kg, the DSP-AZ2 is built with a solid construction that complements its powerful performance. Whether you’re enjoying movies, music, or gaming, the Yamaha DSP-AZ2 offers a high-quality audio experience with its versatile features and exceptional sound capabilities.

Specifications

Power output: 130 watts per channel into 8Ω (stereo)

Surround output: 130W (front), 130W (center), 130W (rear)

Frequency response: 10Hz to 100kHz

Total harmonic distortion: 0.02%

Damping factor: 200

Input sensitivity: 2.5mV (MM), 150mV (line)

Signal to noise ratio: 80dB (MM), 96dB (line)

Channel separation: 55dB (MM), 45dB (line)

Output: 150mV (line), 1V (Pre out)

Digital inputs: coaxial, optical

Video Connections: component, composite, SVHS
