Item Condition: Used
Shipping Options: Pickup available and you can audition.
Suburb or Town: Revesby
State: NSW
Payment Method: Cash
Reason for selling: Upgrading
Further Information:
Continuous power output:
250 watts RMS x 2, 20 Hz - 20 kHz, 8 Ω, all channels driven
400 watts RMS x 2, 20 Hz - 20 kHz, 4 Ω, all channels driven
750 watts RMS x 1, 20 Hz - 20 kHz, 8 Ω
Current capacity:
60 amperes peak per channel
Power bandwidth:
5 Hz - 100 kHz, +0/-3 dB at 1 watt
Total harmonic distortion:
< 0.2 % at full power
Damping factor: > 1100 at 20 Hz
Circuitry designed by legendary John Curl
THX Ultra2 certified
High bias Class A/AB operation
Balanced inputs with discrete circuits and XLR connectors
Direct Coupled - no capacitors or inductors in signal path
Complementary MOSFET driver stage and JFET input stage
16 beta-matched 15 amp, 60 MHz bipolar output transistors
1.2 kVA encapsulated toroid power transformer with independent secondary windings for each channel
88,000 µF power supply filter capacitance
DC Servo and relay protection circuits
AC present, channel status, high temperature indicators
Heavy-duty 24k gold-plated 5-way speaker terminals
Gold-plated RCA input jacks; ground lift switch
Auto turn-on by 12v trigger or audio signal, 12v trigger out
